Features:
1. Small size, waterproof, anti vibration, standard package;
2. The insulation voltage between chip and base plate is AC ≥ 2500V;
3. Vacuum + hydrogen filling protection welding technology, standardized size;
4. Excellent temperature characteristic and power cycle capability;
5. It is easy to install and maintain.

Application:
1. Excitation power supply of DC motor and input rectification of switching power supply;
2. DC power supply of instrument, input rectifier power supply of PWM inverter;
3. Electrical and auxiliary power supply for remote control system of CNC machine tools;
4. Current charging DC power supply for inverter welding machine.

Code: M106A
